Single IGBT Gate Driver MC33153 Mosft Driver

The MC33153 is specifically designed as an IGBT driver for high

power applications that include ac induction motor control, brushless

dc motor control and uninterruptable power supplies. Although

designed for driving discrete and module IGBTs, this device offers a

cost effective solution for driving power MOSFETs and Bipolar

Transistors. Device protection features include the choice of

desaturation or overcurrent sensing and undervoltage detection. These

devices are available in dual−in−line and surface mount packages.


• High Current Output Stage: 1.0 A Source/2.0 A Sink

• Protection Circuits for Both Conventional and Sense IGBTs

• Programmable Fault Blanking Time

• Protection against Overcurrent and Short Circuit

• Undervoltage Lockout Optimized for IGBT’s

• Negative Gate Drive Capability

• Cost Effectively Drives Power MOSFETs and Bipolar Transistors

• This is a Pb−Free and Halide−Free Device
