Specs:

Module name: DC-DC synchronous rectification adjustable step-down module (with housing)

Input: 7V-60V

Output: 1-35V adjustable (maximum can not exceed 35V)

Efficiency: 96% (MAX)

Protection: short circuit protection, reverse connection protection (not connected to the board)

Module size: L70mm*W40mm*H30mm

Module weight: 77g

Working temperature: -40°C-+85°C

Load capacity: 15A (MAX)

Output power: natural heat dissipation 100W, enhanced heat dissipation 150W.

Note: B+ and B- of the boosted battery must not be reversed.

Application: All 3.7-4.2V rechargeable lithium batteries, such as mobile phone battery flat battery 18650 battery and so on!

Can be connected to a lithium battery or parallel multi-cell lithium battery

Lithium battery positive electrode connected to B+      lithium battery negative electrode connected to B-

Attention!!!

Note: B+ and B- of the boosted battery must not be reversed.

The first use requires a Micro USB port to activate once

Tips: This shop has a large number of lithium batteries for sale, you can buy them together! !

 Charging indication: the charging display will show the IN letter

Output load indication: long press the LED light button after the load is turned on, the output starts, the display will show the OUT letter and the relative output voltage and current 5V1A or 5V2.1A

Protection function: The protection circuit of the boosted lithium battery has been integrated to prevent over-discharge, over-charge and overload.

Note: B+ and B- of the boosted battery must not be reversed.

Can be connected to a lithium battery or parallel multi-cell lithium battery

Lithium battery positive electrode connected to B+ lithium battery negative electrode connected to B-

Attention!!!

The first time you need to activate the Micro USB port, you will charge it for 1 minute before using it.

Please check pictures for detail.

It Protects Lithium Battery from Over discharge, Short-circuit, Shack-protect, and overcharges. for more detail please check the detail in the pictures.

Input voltage range: 3.5V-35V ( must ensure that the set output voltage is higher than the input voltage )

Output voltage range: 5.0V-56V

Input maximum current: 3A

Input continuous working current: 2A (good ventilation and heat dissipation conditions, the ratio of output voltage to input voltage cannot be greater than 3)

Appearance size: length * width * height 4.3cm * 3.0cm * 1.2cm
