UBEC DC-DC Converter Step Down Module 3A 5V Mini BEC
close

Features:
UBEC voltage converter to create 5V ouput voltage from 2-6S battery pack input voltage. The UBEC is ideal to provide FPV cameras and GoPro brushless gimbals with a constant 5V voltage.
Mini UBEC
Special for FPV image transmission

Specifications:
Suitable For: RC Air Plane
Output current: constant 3A
Output voltage: 2-6S(5V version)
Size:25*20*7mm
Net Weight: 6g
Weight: 16g

Package Included:
1 X 5V FPV UBEC

320A DC 7.2V-16V Brushed ESC DC motor Speed Controller for Ebike and RC Car Truck Boat
close

Features:
Power range:7.2V-16V
Input voltage(advise):6-12 cells NiMH/NiCd or 2-4 cells LiPo.
Weight:60g (including connectors and switches)
BEC:5.6V 2A
Output current:forward 320A
Out of control protection
Low voltage protection
Over-voltage protection
With heat sink
For 540 dual motor or single motor
Operating system : forward, reverse, and brake
With this power transfer would not have to worry about slow tram Motor Boats only need to
replace the original power transfer
Operational Guidelines:
1.the right and a power supply battery connection on both ends of the wiring board the red
line for positive, black, compared with negative. (Or standard DC battery connection plug Daejeon
male plug / T-plug / banana plug)
2.ESC output red and black wire are connected to the red and black lines of the car 540 motor.
3.open the ESC power switch, if no signal input, motor will send a beep ~ beep ~ beep \"alarm sound.
Turn the transmitter power signal injection will issue the voice of the duo ~ ~ Mi \", has been connected
to prove the transmitted signal and receiving the electrical and mechanical tone.

Specifications:
Net weight:92 g
Package weight:102 g
Color:Black+Red

Package Included:
1 X 320A Brushed ESC

12V~24V 110kg.cm ASMC-04A Robot Servo High Power Torque Support Large Robotic Manipulator For RC Car Quadcopter
close

Description:
Perfectly compatible with for Futaba, for JR, for SANWA, for Hitec and other remote systems.
Exclusive unique technology to ensure stable power steering gear continued to work with other servo fuse protection is completely different. Once the fuse is blown, the servo can not continue to work. Our stability control servo rudder opportunity to work in a safe torque within. And never dropped.

Technical Parameters:
Operating voltage: 12V to 24V (DC) (this means that either a 12V or any voltage between 24V can be used)
No-load rotational current: <500mA
Maximum torque: 110kg.cm (24V) (measured, non-theoretical value)
                               1078N.cm (24V) (measured, non-theoretical value)
                                55kg.cm (12V) (measured, non-theoretical value)
                               539N.cm (12V) (measured, non-theoretical value)

Angular speed: 0.12s / 60 ° (60 degrees of rotation required 0.12s), at 24V  ;
                           0.24s / 60 ° (60 degrees of rotation required 0.24s), at 12V  ;
Rotation angle: 300 ° MAX, meaning that the maximum stroke of 300 degrees (0 to 300 ° adjustable electronic limit)
Input modes: pulse signal (remote control, multiple servo controller, microcontroller) or analog voltage signal (potentiometer)
Pulse signal input range: 0.5ms-2.5ms fits all "multi-channel servo controller", "1ms-2ms model aircraft remote control", "SCM",  and so on;
Voltage signal input range: 0V to + 5V
Control accuracy: 0.32 °
Weight: 530g
Gear Material: Steel
Dimensions: 95.5mm X 60.5mm X 102.6mm

Packet includes:
1 X ASMC-04A Servo

F450 Multi-Copter Quad-copter Kit Frame QuadX Quad MultiCopter (White and Black)
close

Features:
Brand new and high quality
Made by advanced engineering material,super strong & smooth Kit(need you assemble yourself)
New design PCB board for standard 50mm controller board like MK,KK, FF,MWC

Recommended config (Not Included):
A2208 OR A2212 800KV~1100kv brushless motor x4
ESC 15 ~ 25A x4
1800MAH ~ 3600mAh 3S LiPo battery x1
1045 OR 8045 Forward & Reverse propeller x4

Specifications:
Wheelbase: 17.7in/450mm
Color:white+black


Package included:
1 X  F450 MultiCopter Quadcopter Kit

Blue Velcro Battery Strip 27*2cm
close

Blue Strong RC Battery Lipo Antiskid Straps Cable Tie Wire Down 27*2cm

Description:
100% Brand New.
High quality and durable in use, Easy to install.
Product size 27 * 2cm
Color: Blue

Package Included:
1 X Blue Strong RC Battery Lipo Antiskid Straps Cable Tie Wire Down

22 in1 RC USB Flight Simulator Cable for Realflight G7/ G6/ G5 Phoenix 4 E2HG
close

Features:
Perfectly support Real Flight G7/ G6/ G5, Reflex XTR,
Aero Fly and FMS, Car VRC2.0,and etc
Using 4 slide switch for mode selecting,easy to operate.
Completely supports Phoenix: you don't need to decipher, and it supports online
upgrade.
Real Flight G7/ G6/ G5 don't need to run EMU decipherment and the training functions can be used normally.
The adapter cable is compatible with most of mainstream remote controller in market.
High quality and stable performance.

Specifications:
USB port: USB 2.0
Operating System: Windows XP/ Vista/ 7
Supporting software: Phoenix/ XTR/ G4/ G5/ Aero Fly/ FMS
Language: Simplified Chinese/ Traditional Chinese / English
For use with : Windows Vista XP/ Windows7/ Windows8 / Vista
Net Weight: 131g

Package Includes:
1  X  USB simulator
1 X 1.5m audio din cable
3 X patch cord cable
2 X versatile simulator software DVDs


M8N Ublox GPS for APM Pixhawk CC3D Naze32 F3
close

Specification:
Item name: Ublox M8N GPS
Weight: 10g
Size:18*18MM

Features:
1. NMEA 0183 standard output
2. Fast TTFF at low signal level
3.RoHS compliant (Lead-free)
4. UBLOX high sensitivity solution
5. Jamming detection and mitigation
6. Multi-path detection and compensation
7. Built-in 12 multi-tone active interference canceller
8. Free hybrid ephemeris prediction to achieve faster cold start
9. Supports GPS, SBAS (WAAS, EGNOS, MSAS, GAGAN) and QZSS
10. Incorporated external LNA and SAW filter realize high-sensitivity and noise immunity
11. Integrated high sensitivity passive Patch Antenna, Size:18(w)mmX18(d)mmX4(h)mm

Package Includes:
1 X GPS module
1 X 4P wire

LiPo Li-Po Battery Fireproof Safety Guard Safe Bag Charging Sack 18x23
close

Features:
RC Lipo Lithium Polymer Battery Safety Guard Charge Bag The safest way
to charge and store your lipos.
Protect your workshop, family and home from the hazard of lipo charging.
This is a fireproof bag, designed to stop and
contain any fire caused by incorrectly charging poorly functioning lipo packs.
We always urge all of our customers to always practice extreme caution
when charging lithium polymer packs.
Never leave a charging lithium battery unattended.
Size: 180 x 230mm / 7 x 9in (W x L)

Specifications:
Safety and a peace of mind when charging your Lipo\'s!
Original box: NO
Color: Silver
Net weight: 84g
Package weight: 101g

Packing content:
1 x LiPo Battery Safety Guard Charge Bag

Super Bright Sun Readable 5-inch Snow Screen FPV Aerial Video Screen for Sharp Vision
close

 Features:
Super bright
Easy installation
LED backlight
5-inch snow screen display
Accessories complete
3 hours battery life
Anti-Interference
700 Brightness
Built-in battery operating time 2.5-3 hours
Pocket size HD enjoyment
The easiest machine

Specifications:
Fit to: Sharp Vision
Battery operating time: 2.5-3 hours
Ratio: 16: 9
Response time: 10ms
Color standard: PAL / NTSC
Shell Color: white
Size: 12.8 x 8.3 x 1cm
Net weight: 241.9g

Package includes:
1 x screen display (with some Accessories )

M8N NEO GPS Module with Black Shell Case for APM2.6 2.8 Flight Controller
close

Features:
Low power consumption and high precision
Ultimate accuracy: 0.6 meters, actually almost 0.9 meters, greater than the previous generation NEO-7N 1.4-1.6 meters accuracy
Support GPS/QZSS L1 C/A, GLONASS L10F, BeiDou B1 protocol and mode or more.

Specifications:
Receiver type 72-channel u-blox M8 engine
GPS/QZSS L1 C/A, GLONASS L10F, BeiDou B1
SBAS L1 C/A: WAAS, EGNOS, MSAS
Galileo-ready E1B/C (NEO-M8N)
Nav. update rate1 Single GNSS: up to 18 HZ
Concurrent GNSS: up to 10 Hz
Position accuracy2 2.0 m CEP
Acquisition2 Cold starts: 26 s
Aided starts: 2 s
Reacquisition: 1.5 s
Sensitivity2 Tracking & Nav: –167 dBm
Cold starts: –148 dBm
Hot starts: –156 dBm
Assistance AssistNow GNSS Online
AssistNow GNSS Offline (up to 35 days)3
AssistNow Autonomous (up to 6 days)
OMA SUPL & 3GPP compliant
Oscillator TCXO (NEO-M8N/Q),
Crystal (NEO-M8M)
RTC crystal Built-In
Noise figure On-chip LNA (NEO-M8M). Extra LNA for
lowest noise figure (NEO-M8N/Q)
Anti jamming Active CW detection and removal. Extra
onboard SAW band pass filter (NEO-M8N/Q)
Memory ROM (NEO-M8M/Q) or Flash (NEO-M8N)
Supported antennas Active and passive
Odometer Travelled distance
Data-logger For position, velocity, and time (NEO-M8N)
Operating temp. –40 °c to 85 °c
Storage temp. –40°c to 85°c (NEO-M8N/Q)
-40°c to 105°c (NEO-M8M)
RoHS compliant (lead-free)
Qualification according to ISO 16750
Manufactured and fully tested in ISO/TS 16949 certified production sites
Uses u-blox M8 chips qualified according to AEC-Q100
Supply voltage 1.65 V to 3.6 V (NEO-M8M)
2.7 V to 3.6 V (NEO-M8N/Q)
Power consumption4 23 mA @ 3.0 V (continuous)
5 mA @ 3.0 V Power Save Mode
(1 Hz, GPS mode only)
Backup Supply 1.4 to 3.6 V
NEO-M8N-0 u-blox M8 Concurrent GNSS LCC Module,
TCXO, flash, SAW, LNA,
Timepulse Configurable 0.25 Hz to 10 MHz
Color: black
Size: 77*115*12mm
Net weight: 33g

Package including:
1 X NEO-M8N GPS Module with translucent Shell for APM2.6 2.8

25mm Strongest Fiber Tape Transparent Tape Stripe 50meter for Lipo Battery Cells Holding and protection
close

Mesh fiber tape transparent tape stripe 25mm* 25 m

USB GPS BT-708 u-blox G7020-KT Module Receiver Dongle with Antenna
close

Description:
This GPS receiver is GPS receiver is UBLOX 7 generation chip, USB interface, USB level, 9600 baud rate, NMEA-0183 protocol output

The GPS receiver need to install the driver,Driver link https://www.u-blox.com/en/product/u-center-windows
Support Windows only


Feature:
Chipset: u-blox G7020-KT
Receiving Format: GPS,QZSS and SBAS
Frequency: GPS L1,SBAS L1
Channels: 56 Searching Channel
Tracking: -162dBm
Reacquisition: -160dBm
Cold start: -148dBm
Position Horizontal: 2.0 m CEP 2D RMS SBAS Enable (Typical Open Sky)
Velocity: 0.1m/sec 95% (SA off)
Timing: 1us synchronized to GPS time
Cold Start: 29S
Warm Start: 25S
Hot Start: 1S
Support Rate: 4800bps to 921600bps,Default 9600bps
Data Level: Default USB level
Data Protocol: USB, TTL or RS232, Default NMEA-0183
Concurrent GNSS: 1Hz-10Hz,Default 1Hz
Altitude: 50,000m Max
Velocity: 515m/s Max
Acceleration: Less than 4g

VCC: DC Voltage 3.6V-5.5V,Typical: 5.0V
Current: Capture 65mA@5.0V
Dimension: ΦO=56mm*18mm
Connector: USB 2.0 interface
Cable Length: 2.0m

Operating temp: -40 °C ~ +85°C
Storage Temp: -40°C ~ +105°C


Package Includes:
1 X USB GPS Module
