TCRT1000 (OPTOCOUPLER ) REFLECTIVE OPTICAL SENSOR WITH TRANSISTOR

TCRT1000 (OPTOCOUPLER ) REFLECTIVE OPTICAL SENSOR WITH TRANSISTOR

Description:

Optical Sensor (Switch) Reflective; No. of Channels:1; Optocoupler Output Type:Transistor; Input Current Max:50mA; Output Voltage Max:32V; Package/Case:SIP; Leaded Process Compatible:Yes; Operating Temperature Range:- 40°C to +85°C ;RoHS Compliant: Yes

Specification:

Type of semiconductor component

optocoupler

Kind of optocoupler

reflective

Output type

transistor

Current transfer ratio at forward current

2.5%@20mA

Collector-emitter voltage

32V



Schematic Link: https://www.dropbox.com/s/lk9zshnv34jti7b/TCRT1000.pdf

TCRT1000 Pinout, Pinouts
TCRT1000 pinout,Pin out
This is one bundle pinout of TCRT1000, If you require more pinouts please download TCRT1000's pdf datasheet.
