(0V -200V/ 50A-100A) Volt and Ampere Meter Red and Blue Display YB27VA

specifically:

  • Input Power: DC 4.5 - 30 v
  • measure voltage: dc 0-300 v
  • voltage
  • voltage> = 100 v, resolution: 1 v
  • measure current: 50A - 100A  ( require shunt to measure the current, please check the image description for the reference link)
  • current resolution: 0.1a
  • Operating Current: <20ma
  • Display: 0:28 "led, in two colors, red and blue
  • size: 48 x 29 x 21 mm
  • Cutting size: 45 x 26 mm
  • Measuring rate: ≥ 500 ms / times
  • Precision: 1% (  ± 1 digit)
  • Operating temperature: - 10 ° C ~ + 65 ° c
  • Operating Humidity: 10 ~ 80% (non-condensing)
  • operating pressure: 80 ~ 106 kpa
  • Applications: suitable for automotive / electricity sector car / motorcycle battery monitoring or other products of the current voltage measurement.
