3.3V LP2985-33DBVR LP2985 SOT-23-5 Low Dropout Regulator IC

Part no: LP2985-33DBVR
Package: SOT-23-5
Datasheet: http://www.ti.com/lit/ds/symlink/lp2985.pdf

LM358 LM358DR IC SOP-8 Dual Operational Amplifier IC SOIC-8

Datasheet: http://www.ti.com/lit/ds/symlink/lm2904.pdf

5V AMS1117-5.0 Full Range SOT-223 Regulator IC

Datasheet : http://www.advanced-monolithic.com/pdf/ds1117.pdf

PC817 DIP-4 OptoCoupler (EL817)

Datasheet: http://www.sharp-world.com/products/device/lineup/data/pdf/datasheet/pc817xnnsz_e.pdf

5pcs 0805 SMD Resistor 470R 1% 470E (Screen Printing: 4700 471) (5pcs Strip)

New Original CP2102 CP2102-GMR QFN-28 USB to TTL / UART IC

Part No: CP2102-GMR
package: QFN-28
Datasheet: https://www.silabs.com/documents/public/data-sheets/CP2102-9.pdf

ATMEGA328P-PU DIP-28 with 16MHz Crystals HC-49S 2PCS Ceramic Capacitors 22pf

ATMEGA328P-PU DIP-28+16MHz Crystals HC-49S+2PCS Ceramic Capacitors 22pf

3.3V 1A Voltage Regulator AMS1117-3.3 Full Range SOT-223 Low Dropout

Datasheet: http://www.advanced-monolithic.com/pdf/ds1117.pdf

5pcs 0805 SMD Resistor 220R 1% (screen printing: 2200 or 221) (5pcs Strip)

Atmega2560 16AU TQFP-100 AVR Microcontroller IC Original New SMD

Datasheet: http://ww1.microchip.com/downloads/en/DeviceDoc/Atmel-2549-8-bit-AVR-Microcontroller-ATmega640-1280-1281-2560-2561_Summary.pdf


• High Performance, Low Power Atmel® AVR® 8-Bit Microcontroller

• Advanced RISC Architecture

– 135 Powerful Instructions – Most Single Clock Cycle Execution

– 32 × 8 General Purpose Working Registers

– Fully Static Operation

– Up to 16 MIPS Throughput at 16MHz

– On-Chip 2-cycle Multiplier

• High Endurance Non-unstable Memory Segments

– 64K/128K/256KBytes of In-System Self-Programmable Flash

– 4Kbytes EEPROM

– 8Kbytes Internal SRAM

– Write/Erase Cycles:10,000 Flash/100,000 EEPROM

– Data maintenance: 20 years at 85C/100 years at 25C

– Optional Boot Code Section with Independent Lock Bits

• In-System Programming by On-chip Boot Program

• True Read-While-Write Operation

– Programming Lock for Software Security

• Endurance: Up to 64Kbytes Optional External Memory Space

• Atmel® QTouch® library bolster

– Capacitive touch catches, sliders and wheels

– QTouch and QMatrix securing

– Up to 64 sense channels

• JTAG (IEEE® sexually transmitted disease. 1149.1 consistent) Interface

– Boundary-check Capabilities According to the JTAG Standard

– Extensive On-chip Debug Support

– Programming of Flash, EEPROM, Fuses, and Lock Bits through the JTAG Interface

• Peripheral Features

– Two 8-bit Timer/Counters with Separate Prescaler and Compare Mode

– Four 16-bit Timer/Counter with Separate Prescaler, Compare-and Capture Mode

– Real Time Counter with Separate Oscillator

– Four 8-bit PWM Channels

– Six/Twelve PWM Channels with Programmable Resolution from 2 to 16 Bits

(ATmega1281/2561, ATmega640/1280/2560)

– Output Compare Modulator

– 8/16-channel, 10-bit ADC (ATmega1281/2561, ATmega640/1280/2560)

– Two/Four Programmable Serial USART (ATmega1281/2561, ATmega640/1280/2560)

– Master/Slave SPI Serial Interface

– Byte Oriented 2-wire Serial Interface

– Programmable Watchdog Timer with Separate On-chip Oscillator

– On-chip Analog Comparator

– Interrupt and Wake-up on Pin Change

• Special Microcontroller Features

– Power-on Reset and Programmable Brown-out Detection

– Internal Calibrated Oscillator

– External and Internal Interrupt Sources

– Six Sleep Modes: Idle, ADC Noise Reduction, Power-spare, Power-down, Standby,

what's more, Extended Standby

• I/O and Packages

– 54/86 Programmable I/O Lines (ATmega1281/2561, ATmega640/1280/2560)

– 64-cushion QFN/MLF, 64-lead TQFP (ATmega1281/2561)

– 100-lead TQFP, 100-ball CBGA (ATmega640/1280/2560)

– RoHS/Fully Green

• Temperature Range:

– - 40C to 85C Industrial

• Ultra-Low Power Consumption

– Active Mode: 1MHz, 1.8V: 500µA

– Power-down Mode: 0.1µA at 1.8V

• Speed Grade:

– ATmega640V/ATmega1280V/ATmega1281V:

• 0 - 4MHz @ 1.8V - 5.5V, 0 - 8MHz @ 2.7V - 5.5V

– ATmega2560V/ATmega2561V:

• 0 - 2MHz @ 1.8V - 5.5V, 0 - 8MHz @ 2.7V - 5.5V

– ATmega640/ATmega1280/ATmega1281:

• 0 - 8MHz @ 2.7V - 5.5V, 0 - 16MHz @ 4.5V - 5.5V

– ATmega2560/ATmega2561:

• 0 - 16MHz @ 4.5V - 5.5V

0.2A/40V MMBT3904 NPN Switching Transistor Mark: H1A pacakge: SOT23-3

Datasheet: https://www.diodes.com/assets/Datasheets/ds30036.pdf

MCP23017-E/SP - I/O Expander, 16bit, 1.7 MHz, I2C, Serial, 1.8 V, 5.5 V, DIP

The MCP23017-E/SP consists of multiple 8 bit configuration registers for input, output and polarity selection. The system master can enable the I/Os as either inputs or outputs by writing the I/O configuration bits (IODIRA/B). The data for each input or output is kept in the corresponding input or output register. The polarity of the Input Port register can be inverted with the Polarity Inversion register. All registers can be read by the system master.
  • 16 bit remote bidirectional I/O port
  • High speed I2C interface
  • Three hardware address pins to allow up to eight devices on the bus
  • Configurable interrupt output pins
  • INTA and INTB can be configured to operate independently or together
  • Configurable interrupt source
  • Polarity Inversion register to configure the polarity of the input port data
  • External Reset input
  • Low standby current: 1µA max.


Automation & Process Control, Automotive, Clock & Timing, Consumer Electronics, Aerospace, Defence, Military, Embedded Design & Development, LED Lighting, Industrial, Motor Drive & Control
