Description:
Working voltage: 3V-12V
Working current: 20-28mA.
Working temperatur: -10 degree to +70 degree
Resonance mode: sound wave resonance (SAW) Modulation mode: ASK /OOK
Working frequency: 315MHz-433.92MHz,
customized frequency is available.
Transmission distance:>500m,sensitivity to -103dBm, in open areas.
Transmission power: 25mW (315MHz at 12V)
Frequency error: +150kHz (max)
Velocity:10Kbps
Self-owned codes: negative RX Technical
Static current:4MA
Working temperatur: -10 degree to +70 degree
Working principle: single chip superregeneration receiving
Working method: OOK/ASK
Bandwidth: 2MHz (315MHz, having result from testing at lowing the sensitivity 3dBm)

Package includs:
1 X RF transmitter
1 X RF receiver
Please read the description carefully before buying.
